Thermaltake CTE C700 Air Mid Tower Chassis - Black (CA-1X7-00F1WN-00)

Thermaltake CTE C700 Air Mid Tower Chassis - Black

The Thermaltake CTE C700 Air, part number CA-1X7-00F1WN-00, is a spacious E-ATX mid tower chassis designed around Thermaltake’s Centralized Thermal Efficiency concept.

Its internal layout rotates the motherboard tray by 90 degrees, bringing the CPU area closer to the front intake and the graphics card closer to the rear intake path. This is designed to improve direct airflow to major heat-generating components.

CTE 90° Rotated Motherboard Layout

Thermaltake’s CTE design changes the traditional motherboard orientation by rotating it 90 degrees.

This layout is intended to create more direct airflow paths toward the CPU and GPU while helping hot air move upward through the chassis.

Three Pre-Installed 140mm CT140 Fans

The case includes 3 × 140mm Thermaltake CT140 fans:

1 × 140mm front intake
1 × 140mm rear intake
1 × 140mm top exhaust

Thermaltake rates these fans at 1500 RPM and 30.5 dBA.

Extensive 420mm AIO Support

The CTE C700 Air supports large liquid-cooling configurations, including:

Front: up to 420mm AIO
Rear: up to 420mm AIO
Bottom: up to 360mm radiator

Thermaltake also lists support for 360mm custom-loop radiators at the front, rear, and bottom positions.

High Fan Capacity

The chassis offers broad fan support across multiple mounting positions.

Supported fan configurations include up to:

Front: 3 × 120mm / 3 × 140mm / 2 × 200mm
Top: 2 × 120mm / 2 × 140mm
Rear: 3 × 120mm / 3 × 140mm
Bottom: 3 × 120mm / 2 × 140mm
Right side: 1 × 120mm or 1 × 140mm

This gives builders considerable flexibility when tuning airflow for gaming or workstation hardware.

E-ATX Motherboard Support

The CTE C700 Air supports:

Mini-ITX
Micro-ATX
ATX
E-ATX up to 12 × 13 inches

This makes it suitable for mainstream gaming boards as well as larger enthusiast and workstation motherboards.

Up to 410mm GPU Clearance

Thermaltake specifies graphics-card clearance of:

Up to 410mm without a radiator
Up to 327mm with a radiator

This provides room for many large modern graphics cards.

190mm CPU Cooler Clearance

The chassis supports CPU air coolers up to:

190mm in height

This gives builders enough clearance for many large tower-style air coolers.

Up to 220mm PSU Length

The CTE C700 Air supports standard PS2/ATX-style power supplies up to:

220mm long

Flexible Storage Support

Thermaltake lists storage support for:

Up to 7 × 3.5-inch drives

or

Up to 6 × 2.5-inch drives

This makes the case suitable for high-capacity storage builds as well as SSD-focused gaming systems.

4mm Tempered-Glass Side Panel

The Black CTE C700 Air includes:

1 × 4mm tempered-glass side panel

This allows users to showcase internal components while the airflow-focused front remains perforated.

USB-C Front I/O

Front I/O connectivity includes:

1 × USB 3.2 Gen 2 Type-C
2 × USB 3.0 Type-A
1 × HD Audio

This provides convenient access for high-speed storage, peripherals, headsets, and USB-C accessories.

Rotatable PCIe / Vertical GPU Support

Thermaltake includes a rotatable PCIe and riser mounting bracket, allowing supported GPUs to be installed in different orientations.

A PCIe riser cable is sold separately.

Key Features
Brand: Thermaltake
Series: CTE
Model: CTE C700 Air
Part Number: CA-1X7-00F1WN-00
Product Type: Mid Tower Chassis
Color: Black
Dimensions: 566.5 × 327.6 × 505.5mm
Weight: 15.6kg
Material: SPCC / ABS
Side panel: 1 × 4mm tempered glass
Motherboard support: Mini-ITX / Micro-ATX / ATX / E-ATX
Expansion slots: 7
Pre-installed fans: 3 × 140mm CT140
Maximum AIO radiator support: 420mm front / 420mm rear
Bottom radiator support: Up to 360mm
Maximum GPU length: 410mm without radiator
GPU clearance with radiator: 327mm
Maximum CPU cooler height: 190mm
Maximum PSU length: 220mm
Front I/O: USB-C + 2 × USB 3.0 + HD Audio
Drive support: Up to 7 × 3.5" or 6 × 2.5"
90° rotated motherboard layout
CTE airflow-focused design
Compatibility

Suitable for systems using:

Motherboards

Mini-ITX
Micro-ATX
ATX
E-ATX up to 12 × 13"

Graphics Cards

Up to 410mm without radiator
Up to 327mm with radiator

CPU Air Coolers

Up to 190mm

Power Supplies

Standard PS2 / ATX
Up to 220mm

Liquid Cooling

Up to 420mm AIO front
Up to 420mm AIO rear
Up to 360mm radiator bottom

Ideal For

High-airflow gaming PCs, E-ATX enthusiast builds, large graphics cards, custom liquid cooling, 420mm AIO systems, workstation PCs, content-creation systems, and users who want a spacious chassis with a thermal-performance-focused layout.
