Intel Core i9-14900F 14th Gen Desktop Processor - 24 Cores, 32 Threads, Up to 5.8GHz

Intel Core i9-14900F 14th Gen Desktop Processor

The Intel Core i9-14900F is a high-performance 14th Gen desktop processor designed for gaming, streaming, content creation, heavy multitasking, software development, and demanding professional workloads.

Built on the Intel 7 process, it combines 8 Performance-cores and 16 Efficient-cores for a total of 24 cores and 32 threads, while reaching up to 5.8GHz Max Turbo Frequency.

24-Core Hybrid Architecture

The i9-14900F uses Intel's hybrid architecture with:

8 Performance-cores
16 Efficient-cores
24 total cores
32 total threads

This design helps handle demanding foreground applications while efficiently managing parallel and background workloads.

Up to 5.8GHz Turbo Frequency

Intel specifies:

Max Turbo Frequency: Up to 5.8GHz
Intel Thermal Velocity Boost: Up to 5.8GHz
Intel Turbo Boost Max 3.0: Up to 5.6GHz
Performance-core Max Turbo: Up to 5.4GHz
Efficient-core Max Turbo: Up to 4.3GHz

This high boost performance makes the processor well suited for gaming, creative applications, and demanding single-threaded workloads.

36MB Intel Smart Cache

The processor includes:

36MB Intel Smart Cache
32MB total L2 cache

The large cache helps improve responsiveness in games, productivity software, and data-intensive applications.

DDR5 & DDR4 Memory Support

The i9-14900F supports:

DDR5 up to 5600 MT/s
DDR4 up to 3200 MT/s
Maximum memory capacity: Up to 192GB
Dual-channel memory support

Actual supported capacity and speed also depend on the motherboard.

PCIe 5.0 & PCIe 4.0 Support

Intel lists support for both:

PCI Express 5.0
PCI Express 4.0
Up to 20 PCIe lanes

This makes the processor suitable for modern graphics cards, NVMe storage, and high-performance expansion hardware.

LGA1700 Socket

The Core i9-14900F uses the FCLGA1700 socket.

It is compatible with supported Intel 600-series and 700-series motherboards, although some older boards may require a BIOS update before using a 14th Gen CPU.

65W Processor Base Power

Intel rates the processor at:

Processor Base Power: 65W
Maximum Turbo Power: 219W

Because power consumption can increase significantly under turbo workloads, a capable motherboard, power supply, and cooling setup are recommended for sustained performance.

No Integrated Graphics

The F designation means the i9-14900F has no Intel processor graphics.

A compatible dedicated graphics card is required to provide display output. Intel specifically lists the i9-14900F among its boxed processors without integrated graphics.

Intel Laminar RH1 Cooler Included

The boxed Intel Core i9-14900F includes the Intel Laminar RH1 cooler.

The RH1 features a copper heat column, PWM-controlled fan, and ARGB lighting, and Intel specifically lists the i9-14900F among the boxed processors supplied with this cooler.

Key Features
Brand: Intel
Series: 14th Gen Intel Core i9
Model: Core i9-14900F
Product type: Desktop Processor
Architecture / Code Name: Raptor Lake
Process: Intel 7
Socket: FCLGA1700
Total cores: 24
Performance-cores: 8
Efficient-cores: 16
Total threads: 32
Max Turbo Frequency: Up to 5.8GHz
P-core Max Turbo: Up to 5.4GHz
E-core Max Turbo: Up to 4.3GHz
P-core Base Frequency: 2.0GHz
E-core Base Frequency: 1.5GHz
Intel Smart Cache: 36MB
Total L2 Cache: 32MB
Integrated graphics: None
Memory support: DDR5-5600 / DDR4-3200
Maximum memory: 192GB
PCI Express: PCIe 5.0 and 4.0
Maximum PCIe lanes: 20
Processor Base Power: 65W
Maximum Turbo Power: 219W
Intel Thread Director
Intel Thermal Velocity Boost
Intel Turbo Boost Max Technology 3.0
Intel Hyper-Threading Technology
Compatibility

Suitable for compatible desktop systems using:

LGA1700 motherboards
Supported Intel 600-series chipsets
Supported Intel 700-series chipsets
DDR4 or DDR5 memory depending on motherboard
Dedicated graphics card
Suitable CPU cooling
Adequate system power supply

Always verify motherboard BIOS support before installation.

What's in the Box?

For the boxed i9-14900F package:

Intel Core i9-14900F Processor
Intel Laminar RH1 CPU Cooler
User documentation / processor label materials
Important Note

The Intel Core i9-14900F does not have integrated graphics, so the PC will require a compatible dedicated graphics card for normal display output.

Also, while Intel rates the processor at 65W base power, maximum turbo power can reach 219W, so system builders should ensure adequate cooling and power delivery for demanding workloads.

Ideal For

High-performance gaming PCs, gaming and streaming, video editing, 3D rendering, coding, software development, content creation, workstation-style workloads, virtual machines, and heavy multitasking.
